- SPECS -
| MODEL | TECHNOLOGY | WINGSPAN | AREA | A/R | ARTICLE CODE |
|---|---|---|---|---|---|
| FLOWARCH ADJ REAR WING Y30 - 170 | FULL CARBON | 34 cm | 170 cm² | 6.5 | 30FLADJREW_00_1733 |
| FLOWARCH ADJ REAR WING Y30 - 190 | FULL CARBON | 36 cm | 190 cm² | 6.7 | 30FLADJREW_00_1936 |
| FLOWARCH ADJ REAR WING Y30 - 220 | FULL CARBON | 40 cm | 220 cm² | 6.6 | 30FLADJREW_00_2240 |
- SYSTEM COMPATIBILITY -
Matching Fuselage & Rear Wing to Front Wing
All Dynamic Pro System components share a common connection standard and are fully interchangeable within the range. The table below provides a recommended guide for matching fuselage length and rear wing choice to front wing size and discipline.
| FRONT WING | FUSELAGE | REAR WING | DISCIPLINE |
|---|---|---|---|
| Flying Fish HA 750–900-1050 | Dynamic Pro Rear Fuselage 20 - 23 | Flowarch Adj Rear Wing - Flowarch Rear Wing G10 | Hi Performance Downwind |
| Spinner Pro 530–650-780 | Dynamic Pro Rear Fuselage 20 - 23 | Flowarch Adj Rear Wing - Flowarch Rear Wing G10 | Freestyle |
All Dynamic Pro System components are designed and tested together. Mixing fuselage lengths and rear wing options within the range is encouraged — fine-tuning your setup is part of the Dynamic Pro System experience.
WHAT ARE THE SHIMS?
Shims are small inserts used to adjust the angle of the rear wing, fine-tuning the foil’s lift and stability. The RRD Universal fuselage allows the installation of plastic shims to customize performance. Three options are available: Black (0°), Orange (0.75°), and White (1.5°), giving riders the flexibility to modify their setup for different riding styles and conditions.
WARNING: The sets that use the Universal Plus fuselage, such as the Blaze LTD, Thunder, Mantaray, and Flying Fish, must always be used with a shim included in the RRD set. They cannot be used without one. The Universal Plus Alu Fuselage can only be used with adjustable rear wings.
The Black shim (0°) is in a neutral position, providing balanced pressure on the rider and even weight distribution on the front foot. It ensures a stable and well-balanced board, making it ideal for riders who want to learn and gain maximum confidence with their foil.
The Orange shim (0.75°) creates slightly more pressure under the front foot, offering a good lift during take-off and improved control while riding. It also provides some pop for jumps and aerial maneuvers, making it a great choice for riders looking to progress and perform more dynamic tricks.
